74LVC1G386
3-input EXCLUSIVE-OR gate
Rev. 4 — 9 May 2017
Product data sheet
1 General description
The 74LVC1G386 provides a 3-input EXCLUSIVE-OR function.
The input can be driven from either 3.3 or 5 V devices. This feature allows the use of
these devices in a mixed 3.3 and 5 V environment.
Schmitt-trigger action at all inputs makes the circuit tolerant of slower input rise and fall
time.
This device is fully specified for partial power-down applications using IOFF. The IOFF
circuitry disables the output, preventing the damaging backflow current through the
device when it is powered down.
2 Features and benefits
Wide supply voltage range from 1.65 to 5.5 V
High noise immunity
Complies with JEDEC standard:
JESD8-7 (1.65 V to 1.95 V)
JESD8-5 (2.3 V to 2.7 V)
JESD8B/JESD36 (2.7 V to 3.6 V)
±24 mA output drive (VCC = 3.0 V)
Latch-up performance exceeds 250 mA
CMOS low power consumption
Direct interface with TTL levels
Inputs accept voltages up to 5 V
ESD protection:
HBM EIA/JESD22-A114E exceeds 2 000 V
MM EIA/JESD22-A115-A exceeds 200 V.
SOT363 and SOT457 package
Specified from -40 to +85 °C and -40 to +125 °C.




nexperia

74LVC1G386 Datasheet Preview

74LVC1G386 Datasheet

3-input EXCLUSIVE-OR gate

No Preview Available !

Nexperia
74LVC1G386
3-input EXCLUSIVE-OR gate
3 Ordering information
Table 1. Ordering information
Type number Package
Temperature
range
74LVC1G386GW -40 °C to +125 °C
74LVC1G386GV -40 °C to +125 °C
Name
SC-88
SC-74A
Description
Version
plastic surface-mounted package; 6 leads
plastic surface-mounted package (TSOP6); 6 leads
SOT363
SOT457
4 Marking
Table 2. Marking
Type number
74LVC1G386GW
74LVC1G386GV
Marking code [1]
YH
YH
[1] The pin 1 indicator is located on the lower left corner of the device, below the marking code.
5 Functional diagram
1A
3B
6C
Figure 1. Logic symbol
Y4
mnb143
A
1 =1
3
6
mnb145
Figure 2. IEC logic symbol
4
B
C
Figure 3. Logic diagram
Y
mnb144
74LVC1G386
Product data sheet
All information provided in this document is subject to legal disclaimers.
Rev. 4 — 9 May 2017
© Nexperia B.V. 2017. All rights reserved.
2 / 14
