ATS640JSB

DIFFERENTIAL HALL-EFFECT GEAR-TOOTH SENSOR IC

ATS640JSB Features

* Internal Current Regulator for 2-Wire Operation

* True Zero-Speed Operation

* Self Calibrating

* Extremely Stable Duty Cycle with Temperature

* Fully Optimized Differential Digital Gear-Tooth Sensor IC

* Large Operating Air Gaps

* Air-Gap Independent Switch Points

ATS640JSB Datasheet (668.20 KB)

Preview of ATS640JSB PDF

Datasheet Details

Part number:

ATS640JSB

Manufacturer:

Allegro MicroSystems

File Size:

668.20 KB

Description:

Differential hall-effect gear-tooth sensor ic.
Data Sheet 27627.114a ATS640JSB TRUE ZERO-SPEED, SELF-CALIBRATING, DIFFERENTIAL HALL-EFFECT GEAR-TOOTH SENSOR IC FOR TWO-WIRE APPLICATIONS The ATS6.
