STR-S6411 OFF-LINE SWITCHING REGULATORS WITH POWER MOSFET OUTPUT

www.DataSheet4U.com STR-S6411 AND STR-S6411F OFF-LINE SWITCHING REGULATORS WITH POWER MOSFET OUTPUT DRAIN 1 LATCH OSC. Data Sheet 28101.1 SOURCE 2 GATE POWER GROUND SOFT START OVER-CURRENT PROTECTION V IN 3 PWM + 4 + These devices are specifically designed to meet the requirements for increased integration and reliability in off-line flyback (STR-S6411) and forward (STR-S6411F) converters operating in a fixed-frequency PWM mode. Each device incorporates the primary control and.

STR-S6411 Features

* D E R P N E U Y D L O N O T C E C s PWM Flyback Conversion or Forward Conversion s Output Power to 250 W s Pulse-by-Pulse Current Limiting s Fixed-Frequency 100 kHz PWM s Avalanche-Rated Power MOSFET Switch s Soft Start R O R F E R E s Internal Under-Voltage Lockout and Thermal Shutdown s
