AOT9600

600V N-Channel MOSFET

AOT9600 Features

* VDS (V) = 700V @ 150°C ID = 1.3A RDS(ON) < 9Ω (VGS = 10V) 100% UIS Tested! 100% R g Tested! C iss , C oss , C rss Tested! D G G D S S Absolute Maximum Ratings TA=25°C unless otherwise noted Parameter Symbol VDS Drain-Source Voltage VGS Gate-Source Voltage Continuous Drain Current B Pulsed Drain

AOT9600 General Description

The AOT1N60 has been fabricated using an advanced high voltage MOSFET process that is designed to deliver high levels of performance and robustness in popular AC-DC applications. By providing low RDS(on), Ciss and Crss along with guaranteed avalanche capability these parts can be adopted quickly int.

AOT9600 Datasheet (168.91 KB)

Preview of AOT9600 PDF

Datasheet Details

Part number:

AOT9600

Manufacturer:

Alpha & Omega Semiconductors

File Size:

168.91 KB

Description:

600v n-channel mosfet.
