AN6402 Datasheet, converter equivalent, AnaNavi

AN6402 Features

  • Converter
  • Wide Input Voltage from 4.8V to 40V
  • 3A Output Current
  • Adjustable Output Voltage from 1V to 25V
  • High Efficiency Up to 93%
  • Fixed 350KHz S

PDF File Details

Part number:

AN6402

Manufacturer:

AnaNavi

File Size:

37.56kb

Download:

📄 Datasheet

Description:

350khz synchronous step-down dc/dc converter. The AN6402 is a synchronous step-down DC/DC converter that provides wide 4.8V to 40V input voltage range and 3A continuous load curre

Datasheet Preview: AN6402 📥 Download PDF (37.56kb)
