AD5553 Datasheet, Dacs, Analog Devices

AD5553 Features

• Dacs 16-bit resolution AD5543 14-bit resolution AD5553 ±1 LSB DNL ±1 LSB INL Low noise: 12 nV/√Hz Low power: IDD = 10 µA 0.5 µs settling time 4-quadrant multiplying reference input 2 mA full

PDF File Details

Part number:

AD5553

Manufacturer:

Analog Devices ↗

File Size:

576.45kb

Download:

📄 Datasheet

Description:

14-bit dacs. The AD5543/AD5553 are precision 16-/14-bit, low power, current output, small form factor digital-to-analog converters (DACs). They ar

AD5553 Application

• Applications Automatic test equipment Instrumentation Digitally controlled calibration Industrial control programmable logic controllers GENERAL DES
