AD5555 Datasheet, Dacs, Analog Devices

AD5555 Features

• Dacs 16-bit resolution AD5545 14-bit resolution AD5555 ±1 LSB DNL monotonic ±1 LSB INL 2 mA full-scale current ±20%, with VREF = 10 V 0.5 µs settling time 2Q multiplying reference-input 6.9

PDF File Details

Part number:

AD5555

Manufacturer:

Analog Devices ↗

File Size:

944.59kb

Download:

📄 Datasheet

Description:

16-/14-bit dacs.

AD5555 Application

• Applications Automatic test equipment Instrumentation Digitally controlled calibration Industrial control PLCs Programmable attenuator PRODUCT OVERV
