AD9821 - Complete 12-Bit 40 MSPS Imaging Signal Processor

Analog Devices

📥 Download Datasheet

AD9821 Datasheet Preview — Preview of AD9821 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number: AD9821
Manufacturer: Analog Devices ↗
File Size: 277.56 KB
Datasheet: AD9821_AnalogDevices.pdf
Description: Complete 12-Bit 40 MSPS Imaging Signal Processor

AD9821 Product details

Description

The AD9821 is a complete analog signal processor for imaging applications that do not require Correlated Double Sampling (CDS)..

Features

Differential Sensor Input with 1 V p-p Input Range 0 dB to 36 dB 10-Bit Variable Gain Amplifier (VGA) Low Noise Optical Black Clamp Circuit Analog Preblanking Function 12-Bit 40 MSPS A/D Converter (ADC) 3-Wire Serial Digital Interface 3 V Single-Supply Operation Low Power: 150 mW @ 3 V Supply 48-Lead LQFP Package.
