XTR115 Datasheet, Transmitters, Burr-Brown Corporation

XTR115 Features

• Transmitters q LOW QUIESCENT CURRENT: 200µA q 5V REGULATOR FOR EXTERNAL CIRCUITS q VREF FOR SENSOR EXCITATION: XTR115: 2.5V XTR116: 4.096V q LOW SPAN ERROR: 0.05% q LOW NONLINEARITY ERROR: 0.003% q

PDF File Details

Part number:

XTR115

Manufacturer:

Burr-Brown Corporation

File Size:

932.80kb

Download:

📄 Datasheet

Description:

4-20ma current loop transmitters. The XTR115 and XTR116 are precision current output converters designed to transmit analog 4-to-20mA signals over an industry standard

XTR115 Application

• Applications q 2-WIRE, 4-20mA CURRENT LOOP TRANSMITTER q SMART TRANSMITTER q INDUSTRIAL PROCESS CONTROL q TEST SYSTEMS q COMPATIBLE WITH HART MODEM
