CS80N07A8 Datasheet, Mosfet, CR Micro

✔ CS80N07A8 Features

Fast Switching
Low ON Resistance(Rdson≤7.9mΩ)
Low Gate Charge (Typical Data:51nC)
Low Reverse transfer capacitances(Typical:174pF)
100% Single Pulse avalanche

✔ CS80N07A8 Application

Power switch circuit of adaptor and charger. Absolute（Tc= 25℃ unless otherwise specified）： Symbol Paramet

PDF File Details

CR Micro manufacturer logo

Part number:

CS80N07A8

Manufacturer:

CR Micro

File Size:

491.33kb

Download:

📄 Datasheet

Description:

Silicon n-channel power mosfet. VDSS 70 V CS80N07 A8, the silicon N-channel Enhanced ID（Silicon limited current） 80 A VDMOSFETs, is obtained by advanced Tren

📥 Download PDF (491.33kb)
