PDU1032H ECL-INTERFACED PROGRAMMABLE DELAY LINE

The PDU1032H-series device is a 5-bit digitally programmable delay line. The delay, TDA, from the input pin (IN) to the output pin (OUT) depends on the address code (A4-A0) according to the following formula: TDA = TD0 + TINC * A PIN DESCRIPTIONS IN OUT A0-A4 ENB VEE GND Signal Input Signal Out.

PDU1032H Features

* Digitally programmable in 32 delay steps Monotonic delay-versus-address variation Precise and stable delays Input & outputs fully 10KH-ECL interfaced & buffered Fits 32-pin DIP socket GND ENB 1 2 32 31 PACKAGES GND OUT A0 VEE GND IN 7 8 9 11 26 2
