74LVC1G02 Datasheet, Gate, Diodes

74LVC1G02 Features

• Gate
• Wide Supply Voltage Range from 1.65 to 5.5V
• ± 24mA Output Drive at 3.3V
• CMOS low power consumption
• IOFF Supports Partial-Power-Down Mode Operatio

PDF File Details

Part number:

74LVC1G02

Manufacturer:

DIODES ↗

File Size:

551.59kb

Download:

📄 Datasheet

Description:

Single 2 input positive nor gate. Pin Assignments The 74LVC1G02 is a single 2-input positive NOR gate with a standard push-pull output. The device is designed for op

74LVC1G02 Application

• Applications using IOFF. The IOFF circuitry disables the output preventing damaging current backflow when the device is powered down. The gate perfo
