74LVC1G06 Datasheet, Buffer/driver, Diodes

74LVC1G06 Features

• Buffer/driver
• Wide Supply Voltage Range from 1.65 to 5.5V
• 24mA Sink Current at 3.3V
• CMOS Low Power Consumption
• IOFF Supports Partial-Power-Down Mode Operation

PDF File Details

Part number:

74LVC1G06

Manufacturer:

DIODES ↗

File Size:

442.11kb

Download:

📄 Datasheet

Description:

Single inverter buffer/driver. The 74LVC1G06 is a single inverter gate with an open drain output. The device is designed for operation with a power supply range of

74LVC1G06 Application

• Applications using IOFF. The IOFF circuitry disables the output preventing damaging current backflow when the device is powered down. The open-drain
