AL8806Q Datasheet - Diodes

AUTOMOTIVE GRADE BUCK LED DRIVER

AL8806Q Features

* LED driving current up to 1.5A

* Better than 5% accuracy

* High efficiency up to 98%

* Optimally controlled switching speeds

* Operating input voltage from 6V to 30V

* PWM/DC input for dimming control

* Built-in output open-circuit protection

AL8806Q General Description

The AL8806Q is a step-down DC/DC converter designed to drive LEDs with a constant current. The device can drive up to 8 LEDs, depending on the forward voltage of the LEDs, in series from a voltage source of 6V to 30V. The AL8806Q switches at frequencies up to 1MHz. This allows the use of small size .

AL8806Q Datasheet (831.11 KB)

Preview of AL8806Q PDF

Datasheet Details

Part number:

AL8806Q

Manufacturer:

DIODES ↗

File Size:

831.11 KB

Description:

Automotive grade buck led driver.
