Part number: AP1501A
Manufacturer: DIODES (https://www.diodes.com/)
File Size: 605.24KB
Download: 📄 Datasheet
Description: 5A PWM BUCK DC/DC CONVERTER
include a guaranteed ±4% tolerance on output voltage under specified input voltage and output load conditions, and ±15% on the oscillator frequency. The output version in.
requiring specific change
control (i.e. parts qualified to AEC-Q100/101/200, PPAP capable, and manufactured in IATF 1694.
The AP1501A series are monolithic ICs that are designed for a stepdown DC/DC converter, and possess the ability to drive a 5A load without additional transistor component. Due to reducing the number of external component, the board space can be saved.
