DMN4026SSD Datasheet, Mosfet, Diodes

DMN4026SSD Features

• Mosfet V(BR)DSS 40V RDS(ON) MAX 24mΩ @VGS = 10V 32mΩ @VGS = 4.5V ID TA = +25°C 9.0A 7.8A Description This new generation MOSFET has been designed to minimize the onstate resistance (RDS(ON

PDF File Details

Part number:

DMN4026SSD

Manufacturer:

DIODES ↗

File Size:

297.45kb

Download:

📄 Datasheet

Description:

Dual n-channel mosfet. This new generation MOSFET has been designed to minimize the onstate resistance (RDS(ON)) and yet maintain superior switching perform

DMN4026SSD Application

• Applications Applications
• Motor Control
• Backlighting
• Power Management Functions
• DC-DC Converters
