DT1042-04SO - 4 CHANNEL LOW CAPACITANCE TVS DIODE ARRAY

Diodes

DT1042-04SO Datasheet Preview — Preview of DT1042-04SO PDF

Datasheet Details

Part number	DT1042-04SO
Manufacturer	DIODES ↗
File Size	526.79 KB
Description	4 CHANNEL LOW CAPACITANCE TVS DIODE ARRAY
Datasheet	DT1042-04SO-Diodes.pdf

DT1042-04SO Product details

Description

And Applications This new generation TVS is designed to protect sensitive electronics from the damage due to ESD.The combination of its small size and high ESD surge capability makes it ideal for use in automotive applications. USB modules HDMI ports LVDS SOT26

Features

Low Clamping Voltage, I/O to VSS.
Typical 9V at 10A, 100ns, TLP.
Typical 7.7V at 6A, 8/20μs.
IEC61000-4-2 (ESD): Air.
±16kV, Contact.
±16kV.
4 Channels of ESD Protection.
Low Channel Input Capacitance of 0.65pF Typical.
TLP Dynamic Resistance: 0.25Ω.
Typically Used for High-Speed Ports Such as USB 2.0.
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2).
Halogen and Antimony Free. “Green” Device (Note 3).
The DT1042-04S.
