DFM600LXS18-A000 Datasheet, Information, Dynex

✔ DFM600LXS18-A000 Features

s Low Reverse Recovery Charge s High Switching Speed s Low Forward Voltage Drop s Isolated Base KEY PARAMETERS VRRM VF (typ) (max) IF (max) IFM 1800V 2.0V 600A 1200A A

✔ DFM600LXS18-A000 Application

s Brake Chopper Diode s Boost and Buck Converters s Free-wheel Circuits s Motor Drives s Resonant Converters

PDF File Details

Dynex manufacturer logo

Part number:

DFM600LXS18-A000

Manufacturer:

Dynex

File Size:

93.21kb

Download:

📄 Datasheet

Description:

Fast recovery diode module preliminary information.

📥 Download PDF (93.21kb)
