EML3172 Datasheet, Converter, Elite Semiconductor

✔ EML3172 Features

Wide Operating Voltage Ranges : 2.5V to 5.5V
3A Output Current
High efficiency Buck Power Converter
Auto-select PSM/PWM
LDO mode: duty cycle: 100%
Synchronous

✔ EML3172 Application

Cellular telephone
Wireless and DSL Modems
Digital Still Cameras
Portable Products
MP3 Players Ty

PDF File Details

Elite Semiconductor manufacturer logo

Part number:

EML3172

Manufacturer:

Elite Semiconductor

File Size:

523.46kb

Download:

📄 Datasheet

Description:

Synchronous step-down dc-dc converter. EML3172 is a high efficiency, DC-DC synchronous buck converter which provides 3A output loading after output voltage reach preset vol

📥 Download PDF (523.46kb)
