74LS12 Dual Retriggerable One-Shot

74LS12 Description

w w w .D a t a S h e e t 4 U .c o m DM74LS123 Dual Retriggerable One-Shot with Clear and Complementary Outputs August 1986 Revised April 2000 DM7.
The DM74LS123 is a dual retriggerable monostable multivibrator capable of generating output pulses from a few nano-seconds to extremely long duration.

74LS12 Features

* s DC triggered from active-HIGH transition or active-LOW transition inputs s Retriggerable to 100% duty cycle s Compensated for VCC and temperature variations s Triggerable from CLEAR input s DTL, TTL compatible s Input clamp diodes Ordering Code: Order Number DM74LS123M DM74LS123SJ DM74LS123N P

📥 Download Datasheet

Preview of 74LS12 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
74LS12
Manufacturer
Fairchild Semiconductor
File Size
133.30 KB
Datasheet
74LS12_FairchildSemiconductor.pdf
Description
Dual Retriggerable One-Shot
