FAN7085_GF085 High Side Gate Driver

The FAN7085_GF085 is a high-side gate drive IC with reset input and built-in recharge FET. It is designed for high voltage and high speed driving of MOSFET or IGBT, which operates up to 300V. Fairchild's high-voltage process and common-mode noise cancellation technique provide stable operation in th.

FAN7085_GF085 Features

* Qualified to AEC Q100

* Floating channel designed for bootstrap operation fully oper- ational up to 300V.

* Tolerance to negative transient voltage on VS pin

* dv/dt immune.

* Gate drive supply range from 4.5V to 20V

* Under-voltage lockout
