HUF75332G3 - N-Channel MOSFET

HUF75332G3 Description

Data Sheet HUF75332P3 October 2013 N-Channel UltraFET Power MOSFET 55 V, 60 A, 19 mΩ These N-Channel power MOSFETs are manufactured using the innova.

HUF75332G3 Features

* 60A, 55V
* Simulation Models - Temperature Compensated PSPICE® and SABER™ Models - SPICE and SABER Thermal Impedance Models Available on the WEB at: www. fairchildsemi. com
* Peak Current vs Pulse Width Curve
* UIS Rating Curve
* Related Literature - TB334, “G

HUF75332G3 Applications

* where power efficiency is important, such as switching regulators, switching converters, motor drivers, relay drivers, low-voltage bus switches, and power management in portable and batteryoperated products. Formerly developmental type TA75332. Ordering Information PART NUMBER HUF75332P3 PACKAGE

📥 Download Datasheet

Preview of HUF75332G3 PDF
datasheet Preview Page 2 datasheet Preview Page 3
