FR9202T Datasheet, Converter, Fiti

FR9202T Features

  • Converter
  • Low RDS(ON) Integrated Power MOSFET (145mΩ/90mΩ)
  • Wide Input Voltage Range: 4.5V to 18V
  • Output Voltage Range: 0.765V to 8V
  • 2A Output Current

PDF File Details

Part number:

FR9202T

Manufacturer:

Fiti

File Size:

1.35MB

Download:

📄 Datasheet

Description:

2a synchronous step-down dc/dc converter. The FR9202T is a synchronous step-down DC/DC converter with fast constant on time (FCOT) mode control. The device provides 4.5V to 18

Datasheet Preview: FR9202T 📥 Download PDF (1.35MB)
Page 2 of FR9202T Page 3 of FR9202T

FR9202T Application

  • Applications
  • STB (Set-Top-Box)
  • LCD Display, TV
  • Distributed Power System
  • Networking, XDSL Modem Pin Assignme
