1N1122A - Silicon Standard Recovery Diode

This page provides the datasheet information for the 1N1122A, a member of the 1N1199A Silicon Standard Recovery Diode family.

Datasheet Summary

Features

  • High Surge Capability.
  • Types from 50 V to 600 V VRRM.
  • Not ESD Sensitive Note: 1. Standard polarity: Stud is cathode. 2. Reverse polarity (R): Stud is anode. 3. Stud is base. 1N1199A thru 1N1206AR VRRM = 50 V - 600 V IF = 12 A DO-4 Package Maximum ratings, at Tj = 25 °C, unless otherwise specified Parameter Symbol Conditions 1N1199A(R) 1N1200A(R) 1N1202A(R) 1N1204A(R) 1N1206A(R) Unit Repetitive peak reverse voltage RMS reverse voltage DC blocking voltage Continu.

📥 Download Datasheet

Datasheet preview – 1N1122A

Datasheet Details

Part number 1N1122A
Manufacturer GeneSiC
File Size 735.07 KB
Description Silicon Standard Recovery Diode
Datasheet download datasheet 1N1122A Datasheet
Additional preview pages of the 1N1122A datasheet.
