HM3207 - N-Channel Power MOSFET

Product Overview

H&M semi

📥 Download Datasheet

HM3207 N-Channel Power MOSFET by H&M semi - Datasheet Preview — Datasheet preview – HM3207

Datasheet Details

Part number	HM3207
Manufacturer	H&M semi
File Size	492.97 KB
Description	N-Channel Power MOSFET
Datasheet	HM3207 Datasheet
Additional preview pages of the HM3207 datasheet.

Product details

Description

The +0 uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge.

Features

VDSS =75V,ID =210A RDS(ON) < 4mΩ @ VGS=10V Schematic diagram.
Good stability and uniformity with high EAS.
Special process technology for high ESD capability.
High density cell design for ultra low Rdson.
Fully characterized avalanche voltage and current.
Excellent package for good heat dissipation +0.
