HEDL-5600 Datasheet, Drivers, Hewlett-Packard

HEDL-5600 Features

• Drivers
• Available on Both Encoder Modules (HEDS-9000 Series) and Encoder Kit Housing (HEDS-5500 Series)
• Complementary Outputs
• Industry Standard Line Driver IC

PDF File Details

Part number:

HEDL-5600

Manufacturer:

Hewlett-Packard

File Size:

106.67kb

Download:

📄 Datasheet

Description:

Encoder line drivers. Line Drivers are available for the HEDS-55xx/56xx series and the HEDS-9000/9100/9200/9040/ 9140 series encoders. The line driver offe

HEDL-5600 Application

• Applications Eg. ABS braking systems, power steering, life support systems and critical care medical equipment. Please contact sales representative
