HX6001 Datasheet, Charger, Hexin Semiconductor

HX6001 Features

• Charger Programmable Charge Current Up to 800mA No MOSFET, Sense Resistor or Blocking Diode Required Complete Linear Charger for Single Cell Lithium-Ion Batteries Constant-Current/Constant-Volt

PDF File Details

Part number:

HX6001

Manufacturer:

Hexin Semiconductor

File Size:

360.69kb

Download:

📄 Datasheet

Description:

Standalone linear li-lon battery charger. The HX6001 is a complete constant-current/ constant voltage linear charger for single cell lithium-ion batteries. Its package and low

HX6001 Application

• Applications Charger for Li-Ion Coin Cell Batteries Portable MP3 Players, Wireless Headsets Bluetooth Applications Multifunction Wristwatches Descr
