IP00C721, IP00C721_I - Image Scaling Device Up to Wide-XGA

I-Chips

Datasheet Details

Part number	IP00C721, IP00C721_I
Manufacturer	I-Chips
File Size	708.02 KB
Description	Image Scaling Device Up to Wide-XGA
Datasheet	IP00C721_I-Chips.pdf
Note	This datasheet PDF includes multiple part numbers: IP00C721, IP00C721_I. Please refer to the document for exact specifications by model.

The IP00C721 is a low-cost device for real-time image resizing and frame rate conversion up to Wide-XGA resolution output.

a 4x4 pixel interpolation core, with higher sub-pixel resolution than previous devices. The IP00C721 has 2 image input ports: 1) digital RGB 24 bits up to 108 MHz, and 2) digital YUV up to 80 MHz. The output image port can be either 24 bits or 30 bits with a maximum speed of 80 mpixels/sec, and can be driven by an internal or external pixel clock. Lower bit resolutions are also supported for 18-bit display devices. The input and output image ports are completely independent to allow simultaneous.
