2N6653 NPN Transistor

2N6653 Description

isc Silicon NPN Power Transistor .
High Voltage Capability. High Current Current Capability. Low Collector Saturation Voltage. High Switching Speed. Minimum Lot-to-L.

2N6653 Applications

* Desinged for use in switching and linear applications in military and power conversion. Absolute maximum ratings(Ta=25℃) SYMBOL PARAMETER VCBO Collector-Base Voltage VCEO Collector-Emitter Voltage VEBO Emitter-Base Voltage IC Collector Current-Continuous ICM Collector Current-Peak

📥 Download Datasheet

Preview of 2N6653 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
2N6653
Manufacturer
INCHANGE
File Size
182.34 KB
Datasheet
2N6653-INCHANGE.pdf
Description
NPN Transistor
