2SA968B PNP Transistor

2SA968B Description

isc Silicon PNP Power Transistor INCHANGE Semiconductor 2SA968B .
Collector-Emitter Breakdown Voltage : V(BR)CEO= -200V(Min). Good Linearity of hFE. Complement to Type 2SC2238B. Minimum Lot-to-Lot va.

2SA968B Applications

* Power amplifier applications
* Driver stage amplifier applications ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage -200 V VCEO Collector-Emitter Voltage -200 V VEBO Emitter-Base Voltage -5 V IC Collector Current-Continuous -1.5 A I

📥 Download Datasheet

Preview of 2SA968B PDF
datasheet Preview Page 2

Datasheet Details

Part number
2SA968B
Manufacturer
INCHANGE
File Size
198.22 KB
Datasheet
2SA968B-INCHANGE.pdf
Description
PNP Transistor
