2SC2791 - NPN Transistor

Datasheet Summary

Description

High Collector-Emitter Breakdown Voltage- : V(BR)CEO= 800V(Min.) High Switching Speed Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS High speed and high voltage switching applications Switching regulator applications High

📥 Download Datasheet

Datasheet preview – 2SC2791

Datasheet Details

Part number 2SC2791
Manufacturer INCHANGE
File Size 185.95 KB
Description NPN Transistor
Datasheet download datasheet 2SC2791 Datasheet
Additional preview pages of the 2SC2791 datasheet.

📁 Similar Datasheet

  • 2SC2791 - SILICON POWER TRANSISTOR (SavantIC)
  • 2SC2791 - Silicon NPN Transistor (Toshiba)
  • 2SC2790 - Silicon NPN Transistor (Toshiba)
  • 2SC2792 - SILICON POWER TRANSISTOR (SavantIC)
  • 2SC2792 - Silicon NPN Transistor (Toshiba)
  • 2SC2793 - SILICON POWER TRANSISTOR (SavantIC)
  • 2SC2793 - Silicon NPN Transistor (Toshiba)
  • 2SC2794 - SILICON POWER TRANSISTOR (SavantIC)
  • 2SC2798 - NPN EPITAXIAL PLANAR TYPE TRANSISTOR (Mitsubishi)
  • 2SC2703 - Silicon NPN TRANSISTOR (Toshiba Semiconductor)
Other Datasheets by INCHANGE

Full PDF Text Transcription

Click to expand full text
isc Silicon NPN Power Transistor DESCRIPTION ·High Collector-Emitter Breakdown Voltage- : V(BR)CEO= 800V(Min.) ·High Switching Speed ·Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS ·High speed and high voltage switching applications ·Switching regulator applications ·High speed DC-DC converter applications ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage 900 V VCEO Collector-Emitter Voltage 800 V VEBO Emitter-Base Voltage 7 V IC Collector Current-Continuous 5 A IB Base Current-Continuous PC Collector Power Dissipation @ TC=25℃ TJ Junction Temperature 3 A 100 W 150 ℃ Tstg Storage Temperature Range -55~150 ℃ 2SC2791 isc website：www.iscsemi.
