IXTC240N055T, N-Channel MOSFET

isc N-Channel MOSFET Transistor IXTC240N055T *.

datasheet Preview Page 1 from Datasheet4u.com

IXTC240N055T-INCHANGE.pdf

IXTC240N055T Datasheet Preview — Preview of IXTC240N055T PDF

Datasheet Details

Part number:

IXTC240N055T

Manufacturer:

INCHANGE

File Size:

248.07 KB

Description:

N-Channel MOSFET

Features

* Static drain-source on-resistance: RDS(on) ≤ 3.6mΩ@VGS=10V
* Fully characterized avalanche voltage and current
* 100% avalanche tested
* Minimum Lot-to-Lot variations for robust device performance and reliable operation

Applications

* ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE VDSS Drain-Source Voltage 55 VGS Gate-Source Voltage ±20 ID Drain Current-Continuous 240 IDM Drain Current-Single Pulsed 650 PD Total Dissipation @TC=25℃ 480 Tj Operating Junction Temperature -55~175 Tstg Storage Te
