IX4340NE Datasheet, Driver, IXYS

IX4340NE Features

• Driver
• AEC-Q100 qualified
• Two independent drivers, each capable of sourcing and sinking 5A
• 5V to 20V supply voltage range
• AEC-Q100 Grade 1 -40°C to +125

PDF File Details

Part number:

IX4340NE

Manufacturer:

IXYS

File Size:

191.55kb

Download:

📄 Datasheet

Description:

Automotive grade 5-ampere dual low-side mosfet driver. The IX4340NE is an automotive grade, AEC-Q100 qualified dual, high current, low side gate driver. Each of the two outputs is capable

IX4340NE Application

• Applications
• On-board chargers
• DC-DC converters
• Electric vehicle charging stations
• Motor controllers

TAGS

IX4340NE

IXYS
