2SA1308, POWER TRANSISTOR

isc Silicon PNP Power Transistor .
Low Collector Saturation Voltage. Fast Switching Speed. Complement to Type 2SC3308. Minimum Lot-to-Lot variations for robust device p.

datasheet Preview Page 1 from Datasheet4u.com

2SA1308_InchangeSemiconductor.pdf

2SA1308 Datasheet Preview — Preview of 2SA1308 PDF

Datasheet Details

Part number:

2SA1308

Manufacturer:

Inchange Semiconductor

File Size:

198.89 KB

Description:

POWER TRANSISTOR

Applications

* High current switching applications ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage -100 V VCEO Collector-Emitter Voltage -80 V VEBO Emitter-Base Voltage -7.0 V IC Collector Current-Continuous -5 A ICM Collector Current-Peak Collect
