ICS331 Datasheet, Clock, Integrated Circuit Systems

ICS331 Features

  • Clock
  • Packaged as 8 pin SOIC
  • Zero ppm synthesis error in most applications
  • Input crystal frequency from 5 to 27 MHz
  • Input clock frequency from 3 to 50

PDF File Details

Part number:

ICS331

Manufacturer:

Integrated Circuit Systems

File Size:

77.45kb

Download:

📄 Datasheet

Description:

Qtclock single output clock. The ICS331 is a low cost frequency generator that is factory programmable. Using Phase-LockedLoop (PLL) techniques, the device uses a

Datasheet Preview: ICS331 📥 Download PDF (77.45kb)
Page 2 of ICS331 Page 3 of ICS331

ICS331 Application

  • Applications
  • Input crystal frequency from 5 to 27 MHz
  • Input clock frequency from 3 to 50 MHz
  • Output clock frequencies
