ICS8343-01 - 1-TO-16 LVCMOS / LVTTL FANOUT BUFFER

Product Overview

Integrated Circuit Systems

Datasheet Details

Part number	ICS8343-01
Manufacturer	Integrated Circuit Systems
File Size	165.34 KB
Description	1-TO-16 LVCMOS / LVTTL FANOUT BUFFER
Datasheet	ICS8343-01 Datasheet
Additional preview pages of the ICS8343-01 datasheet.

Product details

Description

The ICS8343-01 is a low skew, 1-to-16 LVCMOS/ LVTTL Fanout Buffer and a member of the HiPerClockS™ HiPerClockS™ family of High Performance Clock Solutions from ICS.

Features

16 LVCMOS/LVTTL outputs.
1 LVCMOS/LVTTL clock input.
CLK can accept the following input levels: LVCMOS, LVTTL.
Maximum output frequency: 200MHz.
Dual output enable inputs facilitates 1-to-16 or 1-to-8 input to output modes.
All inputs are 5V tolerant.
Output skew: 250ps (maximum).
Part-to-part skew: 700ps (maximum).
Full 3.3V and 2.5V or mixed 3.3V core/2.5V operating supply.
0°C to 70°C ambient operating.
