IRFH8324, IRFH8324PBF Power MOSFET

International Rectifier

Description

VDS Vgs max RDS(on) max (@VGS = 10V) (@VGS = 4.5V) Qg typ.ID (@Tc(Bottom) = 25°C) 30 V ± 20 V 4.1 mΩ 6.3 14 nC i 50 A Applications *.

Datasheet Specifications

Part number: IRFH8324, IRFH8324PBF
Manufacturer: International Rectifier
File Size: 263.25 KB
Datasheet: IRFH8324PBF-InternationalRectifier.pdf
Description: Power MOSFET
Note: This datasheet PDF includes multiple part numbers: IRFH8324, IRFH8324PBF.
Please refer to the document for exact specifications by model.

Features

* Features Low Thermal Resistance to PCB (< 2.3°C/W) Low Profile (
