HIP6302B Dual Channel Synchronous Rectified Buck MOSFET Driver

PWM1 (Pin 1) and PWM2 (Pin 2), (Pins 15 and 16 QFN) The PWM signal is the control input for the driver. The PWM signal can enter three distinct states during operation, see the three-state PWM Input section under DESCRIPTION for further details. Connect this pin to the PWM output of the controller..

NS W DESIG E N R O NDED F S: C OM ME R E C OMME N D E , R T O N IL L6613A S IS R , INTE Data Sheet 6613 L IS , A 2 , ISL661 14A ISL6612 ISL6614, ISL66 ® HIP6602B July 22, 2005 FN9076.5 Dual Channel Synchronous Rectified Buck MOSFET Driver The HIP6602B is a high frequency, two power channel MOSFET driver specifically designed to drive four power N-Channel MOSFETs in a synchronous rectified buck converter topology. This device is available in either a 14-lead SOIC or a 16-lead QFN package with a.

HIP6302B Features

* Drives Four N-Channel MOSFETs

* Adaptive Shoot-Through Protection

* Internal Bootstrap Devices

* Supports High Switching Frequency - Fast Output Rise Time - Propagation Delay 30ns

* Small 14-Lead SOIC Package

* Smaller 16-Lead QFN Thermally Enhanced

HIP6302B Datasheet (339.59 KB)

HIP6302B Datasheet Preview — Preview of HIP6302B PDF

Datasheet Details

Part number:

HIP6302B

Manufacturer:

Intersil Corporation

File Size:

339.59 KB

Description:

Dual channel synchronous rectified buck mosfet driver.
