LP154W01-TLA3 - WXGA TFT LCD

Datasheet Summary

Description

2 ABSOLUTE MAXIMUM RATINGS 3 ELECTRICAL SPECIFICATIONS 3-1 ELECTRICAL CHARACTREISTICS 3-2 INTERFACE CONNECTIONS 3-3 SIGNAL TIMING SPECIFICATIONS 3-4 SIGNAL TIMING WAVEFORMS 3-5 COLOR INPUT DATA REFERNECE 3-6 POWER SEQUENCE 4 OPTICAL SFECIFICATIONS 5 MECHANICAL CHARACTERISTICS 6 RELIABLITY 7 INTERNAT

Features

  • Active Screen Size Outline Dimension Pixel Pitch Pixel Format Color Depth Luminance, White Power Consumption Weight Display Operating Mode Surface Treatment 15.4 inches diagonal 344.0 (H) Ý 222.0 (V) Ý 6.5(D, max) mm 0.25875 mm Ý 0.25875 mm 1280 horiz. by 800 vert. Pixels RGB strip arrangement 6-bit, 262,144 colors 170 cd/m2(Min. ) , 5 point Total 5.52 Watt(Typ. ) @ LCM circuit 1.1 Watt(Typ. ), B/L input 4.42 Watt(Typ. ) 565g (Typ. ) w/o inverter Transmissive mode, normally white Hard coating(3H) An.

📥 Download Datasheet

Datasheet preview – LP154W01-TLA3

Datasheet Details

Part number LP154W01-TLA3
Manufacturer LG
File Size 887.84 KB
Description WXGA TFT LCD
Datasheet download datasheet LP154W01-TLA3 Datasheet
Additional preview pages of the LP154W01-TLA3 datasheet.

📁 Similar Datasheet

  • LP154WE3-TLA1 - TFT LCD (ETC)
  • LP154WE3-TLB1 - TFT LCD (ETC)
  • LP1500 - 1W POWER PHEMT (Filtronic Compound Semiconductors)
  • LP1500P100 - PACKAGED 1W POWER PHEMT (Filtronic Compound Semiconductors)
  • LP1500SOT223 - Low Noise/ High Linearity Packaged PHEMT (Filtronic Compound Semiconductors)
  • LP1500SOT2231 - Low Noise/ High Linearity Packaged PHEMT (Filtronic Compound Semiconductors)
  • LP1500SOT2232 - Low Noise/ High Linearity Packaged PHEMT (Filtronic Compound Semiconductors)
  • LP1500SOT2233 - Low Noise/ High Linearity Packaged PHEMT (Filtronic Compound Semiconductors)
  • LP1500SOT89 - LOW NOISE/ HIGH LINEARITY PACKAGED PHEMT (Filtronic Compound Semiconductors)
  • LP1503VR - Surface finishing Metal and Wood (FLEX)
Other Datasheets by LG

Full PDF Text Transcription

Click to expand full text
Global LCD Panel Exchange Center www.panelook.com Product Specification SPECIFICATION FOR APPROVAL LP154W01 Liquid Crystal Display ( ) Preliminary Specification ( ̻ ) Final Specification Title BUYER MODEL DELL 15.4” WXGA TFT LCD SUPPLIER LG.Philips LCD Co., Ltd. *MODEL LP154W01 Suffix TLA3 *When you obtain standard approval, please use the above model name without suffix SIGNATURE / / / DATE Please return 1 copy for your confirmation with your signature and comments. APPROVED BY J. H. Lee / S.Manager REVIEWED BY S.R.Kim / Manager PREPARED BY B.H.Kim / Engineer DATE Product Engineering Dept. LG. Philips LCD Co., Ltd Ver. 1.0 Mar,28, 2006 1 / 27 One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.
