LS7183 QUADRATURE CLOCK CONVERTER

LS7183 Description

LSI/CSI UL ® LS7183/LS7184 (631) 271-0400 FAX (631) 271-0405 August 2001 LSI Computer Systems, Inc.1235 Walt Whitman Road, Melville, NY 11747 A380.
The LS7183 and LS7184 are monolithic CMOS silicon gate quadrature clock converters.

LS7183 Features

* x1, x2 and x4 resolution
* Programmable output pulse width (200ns to 140µs)
* Excellent regulation of output pulse width
* TTL and low voltage CMOS compatible I/Os
* +3V to +5.5V operation (VDD-VSS)
* LS7183, LS7184 (DIP) LS7183-S, LS7184-S (SOIC) -
