LT1201 - Op Amps

Datasheet Summary

Features

  • s 1mA Supply Current per Amplifier s 50V/µs Slew Rate s 12MHz Gain-Bandwidth s Unity-Gain Stable s 330ns Settling Time to 0.1%, 10V Step s 6V/mV DC Gain, RL = 2kΩ s 2mV Maximum Input Offset Voltage s 100nA Maximum Input Offset Current s 1µA Maximum Input Bias Current s ±12V Minimum Output Swing into 2kΩ s Wide Supply Range: ±2.5V to ±15V s Drives Capacitive Loads.
