LTC6803-2 - Multicell Battery Stack Monitor

Product Overview

Linear Technology

Datasheet Details

Part number	LTC6803-2
Manufacturer	Linear Technology
File Size	498.79 KB
Description	Multicell Battery Stack Monitor
Datasheet	LTC6803-2 Datasheet
Additional preview pages of the LTC6803-2 datasheet.

Product details

Description

The LTC®6803 is a 2nd generation, complete battery monitoring IC that includes a 12-bit ADC, a precision voltage reference, a high voltage input multiplexer and a serial interface.

Features

Measures Up to 12 Battery Cells in Series Stackable Architecture n Supports Multiple Battery Chemistries and Supercapacitors n Individually Addressable Serial Interface n 0.25% Maximum Total Measurement Error n Engineered for ISO26262 Compliant Systems n 13ms to Measure All Cells in a System n Passive Cell Balancing:.
Integrated Cell Balancing MOSFETs.
Ability to Drive External Balancing MOSFETs n Onboard Temperature Sensor and Thermistor Inputs n 1MHz Serial.
