LTC2863-2 Datasheet, Transceivers, Linear

LTC2863-2 Features

• Transceivers n Protected from Overvoltage Line Faults to ±60V n 3V to 5.5V Supply Voltage n 20Mbps or Low EMI 250kbps Data Rate n ±15kV ESD Interface Pins, ±8kV All Other Pins n Extended Common Mode

PDF File Details

Part number:

LTC2863-2

Manufacturer:

Linear

File Size:

381.42kb

Download:

📄 Datasheet

Description:

Rs485/rs422 transceivers. The LTC®2862/LTC2863/LTC2864/LTC2865 are low power, 20Mbps or 250kbps RS485/RS422 transceivers operating on 3V to 5.5V supplies that

LTC2863-2 Application

• Applications n Supervisory Control and Data Acquisition (SCADA) n Industrial Control and Instrumentation Networks n Automotive and Transportation El
