BAW156 Datasheet, diode equivalent, MCC

BAW156 Features

• Diode
• Halogen free available upon request by adding suffix "-HF"
• Low leakage current: typ. 3pA
• Switching time: typ. 0.8s
• Continuous reverse voltage:max

PDF File Details

Part number:

BAW156

Manufacturer:

MCC

File Size:

240.45kb

Download:

📄 Datasheet

Description:

250mw 75volts dual switching diode.
