MAX8715 - Low-Noise Step-Up DC-DC Converters

MAX8715 Description

19-1563; Rev 3; 9/05 KIT ATION EVALU LE B A IL A AV www.DataSheet4U.com Low-Noise Step-Up DC-DC Converters General .
Features. 90% Efficiency. Adjustable Output from VIN to 12V. 1. 2.

MAX8715 Features

* 90% Efficiency
* Adjustable Output from VIN to 12V
* 1.6A, 0.21Ω, 14V Power MOSFET (MAX1790)
* 2.4A, 0.15Ω, 14V Power MOSFET (MAX8715)
* +2.6V to +5.5V Input Range
* Pin-Selectable 640kHz or 1.2MHz Switching Frequency
* 0.1µA Shutdown Current

MAX8715 Applications

* LCD Displays PCMCIA Cards Portable Applications Hand-Held Devices + Denotes lead-free package. Typical Operating Circuit VIN 2.6V TO 5V Pin Configuration TOP VIEW COMP IN ON/OFF SHDN 1 2 3 8 7 SS FREQ IN LX VOUT LX FB SHDN MAX1790 MAX8715 FREQ GND MAX1790 MAX8715 6 5 GND 4 μMAX SS CO
