MAX1993 - Quick-PWM Step-Down Controllers

This page provides the datasheet information for the MAX1993, a member of the MAX1992 Quick-PWM Step-Down Controllers family.

Description

The MAX1992/MAX1993 pulse-width modulation (PWM) controllers provide high-efficiency, excellent transient response, and high DC output accuracy.

The devices step down high-voltage batteries to generate lowvoltage CPU core or chipset/RAM supplies in notebook computers.
