Part number: 25LC040
Manufacturer: Microchip (https://www.microchip.com/)Technology
File Size: 287.05KB
Download: 📄 Datasheet
Description: 4K SPI Bus Serial EEPROM
* Low-power CMOS technology:
- Write current: 3 mA, typical
- Read current: 500 μA, typical
- Standby current: 500 nA, typical
* 512 x 8-bit organization
<.
The Microchip Technology Inc. 25AA040/25LC040/ 25C040 (25XX040*) is a 4 Kbit serial Electrically Erasable PROM. The memory is accessed via a simple Serial Peripheral Interface (SPI) compatible serial bus. The bus signals required are a clock input (.
Image gallery
