LX8386-33CP 1.5 A LOW DROPOUT POSITIVE REGULATORS

The LX8386/86A/86B series ICs are positive regulators designed to provide 1.5A output current. These regulators yield higher efficiency than currently available devices with all internal circuitry designed to operate down to a 1V input-to-output differential. In this product, the dropout voltage is .

LX8386-33CP Features

* expected of voltage regulators: short circuit protection, safe operating area protection and automatic thermal shutdown if the device temperature rises above approximately 165°C. Use of an output capacitor is REQUIRED with the LX8386/86A/ 86B series. Please see the table below for recommended minimu
