ML62202 Datasheet (Minilogic Device) - Positive Voltage Regulator

ML62202, Positive Voltage Regulator

The ML62 is a group of positive voltage output, three-pin regulator which provides high output current even when the input/output voltage differential is small.

The ML62 consists of a high-precision voltage reference, an error correction circuit, and a current limited output driver.

v Block Diagram

ML62202 Features

* l l l l l l l CMOS Low Power Consumption : Typical 3.3uA at V out=5.0V Output V oltage Range : 2.0V to 6.0V in 0.1V increments Highly Accurate : Output V oltage + 2% Maximum Output Current: 250mA (within the maximum power dissipation , V out=5.0V) Small Input-Output V oltage Differential : 0.12V at
