LPC1115 - (LPC1110 - LPC1115) 32-bit ARM Cortex-M0 microcontroller

This page provides the datasheet information for the LPC1115, a member of the LPC1110 (LPC1110 - LPC1115) 32-bit ARM Cortex-M0 microcontroller family.

Datasheet Summary

Description

The LPC1110/11/12/13/14/15 are an ARM Cortex-M0 based, low-cost 32-bit MCU family, designed for 8/16-bit microcontroller applications, offering performance, low power, simple instruction set and memory addressing together with reduced code size compared to existing 8/16-bit architectures.

Features

  • System:.
  • ARM Cortex-M0 processor, running at frequencies of up to 50 MHz.
  • ARM Cortex-M0 built-in Nested Vectored Interrupt Controller (NVIC).
  • Non-Maskable Interrupt (NMI) input selectable from several input sources (LPC1100XL series only).
  • Serial Wire Debug.
  • System tick timer.
  • Memory:.
  • 64 kB (LPC1115), 56 kB (LPC1114/333), 48 kB (LPC1114/323), 32 kB (LPC1114/102/201/202/203/301/302/303), 24 kB (LPC1113), 16 kB (LPC1112), 8 kB (LPC1111), or 4 kB (LPC1.
